Li-ion & LiFePO4 · built to your specification

Custom Lithium Battery Pack Manufacturer in Malaysia

Tell us the voltage, capacity, discharge current and the space you have. We select the cells and BMS, build the pack, test it and ship it — from a single sample to a production batch.

Send Us Your Battery Requirements WhatsApp Us Now
Samples and batch orders Malaysia-based technical support

Get a custom pack quotation

A few fields to start. We will come back with the questions that matter for your application.

Have a photo of the old battery? Send it on WhatsApp — it speeds things up a lot.

Specification

What we customise on every pack

Nothing here is a fixed catalogue item. Each pack is configured around the equipment it has to run.

ParameterOptions we build
ChemistryLi-ion (NMC) · LiFePO4
Cell format18650 · 21700 · 32700 · 32650
Voltage3.7V · 7.4V · 12V · 24V · 36V · 48V · 52V · 60V · 72V
Capacity5Ah · 12Ah · 20Ah · 60Ah · 100Ah — or specified to your runtime
Power350W · 1000W · 2000W · 3000W
ConfigurationSeries and parallel arranged to fit your compartment
BMSSelected for your current draw — over-charge, over-discharge, over-current and short-circuit protection; balancing on multi-series packs
Discharge currentContinuous and peak rated to your load
DimensionsCell arrangement built to your maximum L × W × H
Wiring & connectorsWire gauge and length to suit; bare leads or matched to your existing plug
EnclosurePVC shrink wrap · plastic case · metal enclosure
TSP battery pack range — 1P to 8P configurations from 3.7V 2600mAh to 12V 5200mAh, in 18650 and 21700 cells

Packs we build, labelled with the configuration each one carries — the series and parallel count, the voltage and the capacity all change with the application.

Finished TSP battery packs with XT60 connectors fitted to the output leads
Replacing an existing battery?

Send a photo of the old pack, its label and the connector. In most cases that is enough for us to quote without any measurements from you.

Application examples

What we build packs for

Every application has its own page with the configurations we normally build for it.

All applications
Solar Street Lights Emergency Lighting Speakers & Singing Machines Toys & RC Equipment Agricultural Sprayers Monitoring & Security Portable Equipment Industrial Equipment UPS & Backup Power Camping & Outdoor Power Solar Energy Storage Commercial Energy Storage

Inside the pack

What we actually build

Every pack is the same five things, arranged around your voltage, your current and the space you have.

Exploded view of a custom lithium battery pack Five layers, top to bottom: outer wrap, protection board, nickel strip, cell block, and output leads with connector. PVC wrap / plastic / metal case 1 2 3 series × parallel to suit the voltage and current 4 5
Illustration, not a photograph — the construction of a typical custom pack.
  1. 1
    Enclosure

    PVC shrink wrap, a plastic case or a metal housing, sized to the compartment the pack has to sit in.

  2. 2
    Protection board (BMS)

    Chosen for your continuous and peak current, with over-charge, over-discharge, over-current and short-circuit protection. Balance leads run to every series group.

  3. 3
    Nickel strip, spot welded

    Welded rather than soldered: the joint carries the current without putting sustained heat into the cell.

  4. 4
    Cell block

    18650, 21700, 32700 or 32650 cells in Li-ion or LiFePO4, arranged in series for the voltage and in parallel for the capacity and current.

  5. 5
    Leads and connector

    Wire gauge sized to the current, length to suit the installation, and the plug your equipment already uses.

Production process

From your message to a tested pack

Cell selectionChemistry and format chosen for the duty
S × P
ConfigurationSeries for voltage, parallel for capacity
Spot weldingWelded joints, no sustained heat in the cell
BMS & wiringProtection sized to your current draw
EnclosureWrapped, cased and labelled to spec
Test & inspectEvery pack charged, discharged and checked
01Requirement Consultation
02Battery Specification Confirmation
03Cell and BMS Selection
04Pack Structure Design
05Assembly and Spot Welding
06Wiring and Connector Installation
07Charging and Discharging Test
08Final Inspection
09Packaging and Delivery

FAQ

Frequently asked questions

Something not covered here? Message us on WhatsApp — a specialist answers directly.

I do not know the specification — can you still help?
Yes. Send a photo of the old battery, its label and the connector, plus what the equipment is. We work the specification out from there and confirm it with you before building anything.
Should I choose Li-ion or LiFePO4?
Li-ion gives more capacity in less space and weight — the usual choice where the battery compartment is tight. LiFePO4 runs cooler, tolerates heat better and lasts far more charge cycles, which makes it the normal choice for solar, standby power and anything installed outdoors in Malaysia. Tell us the application and we will recommend one.
Can you match the original connector and dimensions?
Yes. Send the old pack or a clear photo of it, including the plug and any label. We rebuild to fit the existing compartment and to plug straight into your equipment.
Can I order a single sample before a batch?
Yes — we build single packs so you can test one in your own equipment before committing to a larger order. Message us with your specification and we will confirm the cost and timing for a sample.

Full specification

Request a Custom Battery Quotation

The more of this you can fill in, the more accurate the quotation. Anything you leave blank, we will ask about.

Your details

Battery specification

We reply to every enquiry from wushuang2024@gmail.com. For photos of an existing battery, WhatsApp is fastest.

Send us your battery requirements today

A photo of the old battery is often all we need to get started. Talk to a specialist here in Malaysia — not an overseas call centre.
